Single-phase pad-mounted transformer

Quality-oriented, producing premium products

Single-phase pad-mounted transformer

Rated capacity:10~50kVA

Global information

Product ID: 3.12.66.drp

EAN:–

Catalog Description:

Oil-Immersed transformer/Single-phase pad-mounted transformer

Description:

The basic structure of a single-phase pad-mounted transformer consists of a magnetic core, a primary coil and a secondary coil. The primary coil that is usually composed of thick wires is connected to a power supply. The secondary coil composed of thin wires supplies the output voltage after transformation. The magnetic core is often composed of silicon steel sheets for effective conduction of magnetism and reduction of power loss. The shell is for protection and heat dissipation of internal components.
Single-phase pad-mounted transformers can be configured with the rated capacity (10-50kVA) or customized according to specific needs.
Due to the compact structure, single-phase pad-mounted transformers are ideal for irrigation, oil fields and residence.

Description

Please contact SH POWER

We really have the product you need and we offer it to OEM.

Technical
Transformer types:	Single-phase pad-mounted transformer
Transformer capacity(kVA):	5-250
Primary Voltage(V):	2400~34500
Secondary Voltage(V):	120~600
Frequency (Hz):	50~60
Winding Material:	Aluminum
Anti-corrosion Grade:	C5+
Product functions
Reliable operation and low noise, without moving parts. Extensive applications due to voltage conversion. Long service life because of no mechanical contact. High efficiency in power transmission from one to another circuit
